LFCN-2750+ is a low-pass filter produced by Mini-Circuits.

LFCN-2750+ is a low-pass filter produced by Mini-Circuits.

Functions

• Frequency Filtering
  • It is a low-pass filter with a frequency range of 700 MHz. It allows low-frequency signals to pass through with minimal loss while attenuating high-frequency signals.
  • The insertion loss is only 1 dB, which can efficiently filter out unwanted high-frequency signals.
• Impedance Matching
  • The impedance is 50 ohms, which can match the impedance of the circuit well, ensuring the efficient transmission of signals and reducing signal reflection and loss.
• Compact Package
  • It adopts a 4-SMD, no-lead package, with dimensions of 0.126" L x 0.063" W (3.20 mm x 1.60 mm) and a maximum height of 0.037" (0.94 mm).
  • This compact package is suitable for surface mount applications and is very suitable for high-density printed circuit boards.
• Good Power Handling Capacity
  • The LFCN-530+ (similar model) has an average input power of 8.5W, and the power handling capacity is excellent.
  • The LFCN-530D+ also likely has similar power handling performance, which can meet the requirements of circuits with higher power input.
• Wide Operating Temperature Range
  • The LFCN-530+ can work in the temperature range of -55°C to 100°C.
  • The LFCN-530D+ is also expected to have a wide operating temperature range, which can be applied in harsh environments.
  •

Applications

• Harmonic Rejection
  • It can be used to suppress harmonic signals in electronic circuits, ensuring the purity of the main signal and reducing the impact of harmonics on the system.
• VHF/UHF Transmitters/Receivers
  • It is applicable to filtering in VHF/UHF transmitters and receivers, helping to improve the signal - to - noise ratio of the communication system,
  • reduce interference, and ensure the quality of signal transmission and reception.
• General Filtering
  • It is used for general signal filtering in various electronic devices to remove high - frequency interference signals and improve the stability and performance of the system.
